TRIPLE-PLAY SERIES LED U1 Hybrid Tube – 2FT, 15W, 1,950 Lumens, Type A+B, NSF Rated, (120-277V)

High-Performance 2-Foot U-Bend LED Replacement – 130 lm/W, Hybrid Ballast-Compatible or Bypass, NSF Rated, 5-Year Warranty

The TRIPLE-PLAY SERIES PV-1UB-15WAB1 2-foot LED U1 tube is a high-efficiency, hybrid (Type A+B) solution designed to replace traditional 2FT U-bend fluorescent lamps. Delivering 1,950 lumens at 130 lm/W, this 15W lamp offers the flexibility to operate with or without a ballast, supporting both single-ended and double-ended power installations with G13 end caps.

Engineered for commercial and industrial environments, this lamp features a frosted, shatter-resistant tempered glass lens with PET coating that is NSF certified, making it ideal for use in food-safe and hygienic settings. The anti-UV coating ensures even, long-lasting light without discoloration.

With wide compatibility, robust construction, and UL, FCC, CE, and RoHS certifications, the TRIPLE-PLAY U1 tube qualifies for energy-efficient lighting rebates and is backed by a 5-year / 50,000-hour warranty—making it a premium choice for performance, safety, and efficiency.

Specifications:

Electrical Data:

• Input Voltage: 120-277V

• Input Frequency: 50/60 Hz

• Wattage: 15W

• Power Factor: >0.9

• Operating Temperature: -4°F to 104°F (-20°C to 40°C)

• Driver Type: Type A+B (Hybrid: Ballast Compatible or Bypass)

• Installation: Single and Double-Ended Power

Lighting Performance:

• Lumen Output: 1,950 lm

• Efficacy: 130 lm/W

• CCT Options: 4000K, 5000K

• CRI: Ra ≥83

• Dimmable: No

• L70 Lifetime: 50,000 hours

Construction & Design:

• Length: 2-FT U1 Bend

• Lens Material: Frosted Tempered Glass with PET Coating

• Lens Rating: NSF Certified, Anti-UV

• Color: White

• Shatter-Resistant: Yes

Compatibility & Controls:

• Base Type: G13

• Controls: Compatible with ON/OFF occupancy sensors

Certifications & Warranty:

• Certifications: UL (US & Canada), FCC, CE, RoHS

• NSF Rated: Yes

• Rebate Eligible: Yes

• Warranty: 5 Years / 50,000 Hours
